型號：Q0010-00
|
ZEN: 1.01.0144.0 | WAI: 54-8305 | Lester: 16588 OEM NO: M191T30971, 23312E3010, 22224722, M191T30171 |
||
| No Of Teeth: 9 | Rotation:CW | Length (mm):60 |
| Pinion O.D. (mm):29.52 | No Of Splines:4 | Pinion I.D. (mm):12.8 |
| Drive O.D. (mm):45.3 | ||
型號：J0095-00
|
ZEN: 1.01.0791.0 | WAI: 54-8132 | Lester: 16803 OEM NO: 23312M4902, 23300M4900, 211435507, S114-252 S114-393 |
||
| No Of Teeth: 8 | Rotation:CW | Length (mm):87 |
| Pinion O.D. (mm):28 | No Of Splines:10 | Pinion I.D. (mm): |
| Drive O.D. (mm):53.2 | ||
型號：Q0069-00
|
ZEN: 1.01.0135.0 | WAI: 54-208 | Lester: 3208 OEM NO: 1843041, C8FF11350A, 1838065, 1916775 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):77 |
| Pinion O.D. (mm):25.7 | No Of Splines:4 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48.6 | ||
型號：Y0042-00
|
ZEN: 1.01.0729.0 | WAI: 54-9171 | Lester: 17223 OEM NO: 1006209579, 1006209917, 9001081010, TNB010 |
||
| No Of Teeth:10 | Rotation:CCW | Length (mm):77 |
| Pinion O.D. (mm):28 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Q0040-00
|
ZEN: 1.01.0499.0 | WAI: 54-8101 | Lester: 16774/16674 OEM NO: S114-320A, 211445504, 23312D0100, S114-320 |
||
| No Of Teeth:8 | Rotation:CW | Length (mm):60 |
| Pinion O.D. (mm):28.2 | No Of Splines:5 | Pinion I.D. (mm):12.5 |
| Drive O.D. (mm):48 | ||
型號：Y0037-00
|
ZEN: 1.01.0249.0 | WAI: 54-9401 | Lester: 16751 OEM NO: 181804 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):55.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:9 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Y0026-00
|
ZEN: 1.01.0787.0 | WAI: 54-9434 | Lester: 17667 OEM NO: 186938, 188887, 21020761, 21020892 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):51.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:5 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：J0160-00
|
ZEN: | WAI: 54-8406 | Lester: OEM NO: 6582, 6498, 10456455, 10457121 |
||
| No Of Teeth:10 | Rotation:CW | Length (mm):67 |
| Pinion O.D. (mm):32.1 | No Of Splines:12 | Pinion I.D. (mm):14 |
| Drive O.D. (mm):67 | ||
型號：J0153-00
|
ZEN: 1.01.0818.0 | WAI: 54-8235 | Lester: 17202 OEM NO: 0283006990, 0283007170, 8-94360-113-1, 2810046410 |
||
| No Of Teeth: 9/40 | Rotation:CW | Length (mm):83 |
| Pinion O.D. (mm):29.5 | No Of Splines:10/18 | Pinion I.D. (mm): |
| Drive O.D. (mm):53.9 | ||
型號：J0139-00
|
ZEN: 6.39.792.5 | WAI: 54-82204 | Lester: 16822 OEM NO: 0280008371, 2810064020, 0283004091, 5482204 |
||
| No Of Teeth: 9/40 | Rotation:CW | Length (mm):102.5 |
| Pinion O.D. (mm):36 | No Of Splines:10/18 | Pinion I.D. (mm):14 |
| Drive O.D. (mm):53.9 | ||
型號：Q0128-00
|
ZEN: 1.01.0327.0 | WAI: 54-8205 | Lester: 16218 OEM NO: 0283000801, 0283001690, 2801140010, 28011-41011 |
||
| No Of Teeth: 9 | Rotation:CW | Length (mm):86 |
| Pinion O.D. (mm):29.7 | No Of Splines:5 | Pinion I.D. (mm):12.55 |
| Drive O.D. (mm):47.3 | ||
型號：Q0109-00
|
ZEN: 1.01.0808.0 | WAI: 54-8234 | Lester: 17142 OEM NO: 283006680, 2801187101, 283006710 |
||
| No Of Teeth: 8 | Rotation:CW | Length (mm):53.5 |
| Pinion O.D. (mm):28.2 | No Of Splines:5 | Pinion I.D. (mm):11 |
| Drive O.D. (mm):41.6 | ||
型號：Q0099-00
|
ZEN: 1.01.0184.0 | WAI: 54-8208 | Lester: 16258/16215 OEM NO: 0283001020, D27Z11350A, MD604047, 29024830 |
||
| No Of Teeth: 9 | Rotation:CW | Length (mm):64.5 |
| Pinion O.D. (mm):29.7 | No Of Splines:5 | Pinion I.D. (mm):12.5 |
| Drive O.D. (mm):47.3 | ||
型號：J0098-00
|
ZEN: 6.39.0301.5 | WAI: 54-8241 | Lester: 16881 OEM NO: 0283002011, 2801154010, 283004550, 2810077090 |
||
| No Of Teeth: 11/35 | Rotation:CW | Length (mm):146 |
| Pinion O.D. (mm):40/55.5 | No Of Splines:10/16 | Pinion I.D. (mm): |
| Drive O.D. (mm):59 | ||
型號：J0083-00
|
ZEN: 1.01.0947.0 | WAI: 54-8202-9 | Lester: 16248 OEM NO: 0283001602, 31204657617, 8941566710, 2801126042 |
||
| No Of Teeth:9/40 | Rotation:CW | Length (mm):102.5 |
| Pinion O.D. (mm):29.7 | No Of Splines:10/18 | Pinion I.D. (mm):13.5 |
| Drive O.D. (mm):53.9 | ||
